Stott Park Bobbin Mill, Colton
Stott Park Bobbin Mill
locality:-   Low Stott Park
civil parish:-   Colton (formerly Lancashire)
county:-   Cumbria
locality type:-   bobbin mill
locality type:-   mill
locality type:-   workplace
locality type:-   museum
coordinates:-   SD37228821
1Km square:-   SD3788
10Km square:-   SD38
SummaryText:-   Bobbin mill, built 1835.


photograph
photograph
BLZ43.jpg  Belt driven machinery.
(taken 28.4.2006)

evidence:-   old map:- OS County Series (Lan 8 11)
placename:-  Stott Park Mill
source data:-   Maps, County Series maps of Great Britain, scales 6 and 25 inches to 1 mile, published by the Ordnance Survey, Southampton, Hampshire, from about 1863 to 1948.
"Stott Park Mill (Bobbin)"


photograph
CAJ39.jpg  Wood.
(taken 15.4.2014)
photograph
BTH30.jpg  Wood.
(taken 5.8.2010)
photograph
BTH34.jpg  Wood.
(taken 5.8.2010)
photograph
BTH35.jpg  Wood samples; ash, alder, birch, hazel, sycamore.
(taken 5.8.2010)


photograph
BTH40.jpg  Horizontal steam engine
(taken 5.8.2010)
photograph
BTH41.jpg  Line shafting.
(taken 5.8.2010)
photograph
CAJ41.jpg  Line shafting.
(taken 15.4.2014)
photograph
BTH37.jpg  Blocking machine; cuts bobbin blanks out of a slice of wood.
(taken 5.8.2010)
photograph
CAJ36.jpg  Blocking machine.
(taken 15.4.2014)
photograph
CAJ37.jpg  Blocking machine.
(taken 15.4.2014)
photograph
BTH36.jpg  Blocking saws.
(taken 5.8.2010)
photograph
BTH38.jpg  Circular saw; to cut length off a billet of wood.
(taken 5.8.2010)
photograph
BTH39.jpg  Tally, a cut for every dozen done.
(taken 5.8.2010)
photograph
BTH42.jpg  Bobbin lathe.
(taken 5.8.2010)
photograph
BTH45.jpg  Boring machine; automatic, all the operator does is lift off a drilled blank, and position another.
(taken 5.8.2010)
photograph
BTH46.jpg  Cams on boring machine.
(taken 5.8.2010)
photograph
BTH44.jpg  Bobbins.
(taken 5.8.2010)
photograph
CAJ38.jpg  Swill bakets.
(taken 15.4.2014)
photograph
CAJ42.jpg  Turning shop.
(taken 15.4.2014)
photograph
CAJ44.jpg  Turning shop.
(taken 15.4.2014)
photograph
CAJ50.jpg  Waste, from one lathe. This is used as fuel for the steam engine's boiler, it is also used by the operators to keep themselves warm, by standing thigh deep in it. The workshop doors was kept open to blow away dust, a serious fire hazard.
(taken 15.4.2014)
photograph
BLZ44.jpg  Lathe.
(taken 28.4.2006)
photograph
BTH47.jpg  Cotton reel lathe; the tool head holds a several tools, set to cut the bobbin's shape in one go.
(taken 5.8.2010)
photograph
CAJ49.jpg  Cotton reel lathe.
(taken 15.4.2014)
photograph
CAJ43.jpg  Cotton reel lathe.
(taken 15.4.2014)
photograph
BTH48.jpg  Lathe
(taken 5.8.2010)
photograph
photograph
photograph
CAJ46.jpg  Saw, made by:-
"W A FELL MAKER / BRIDGE IRON WORKS WINDERMERE" (taken 5.8.2010)
photograph
CAJ47.jpg "W A FELL / MAKER" (taken 15.4.2014)
photograph
CAJ48.jpg "BRIDGE IRON WORKS / WINDERMERE" (taken 15.4.2014)
photograph
photograph
BTH50.jpg  Finishing department.
(taken 5.8.2010)
photograph
BTH51.jpg  Finishing; load half full with bobbins, and a few nobs of candle wax, it is rotated by power, and the bobbin get warm, the wax melts and coats them nicely.
(taken 5.8.2010)
photograph
BTH52.jpg  Shellac knotting.
(taken 5.8.2010)
photograph
BTH53.jpg  Finishing.
(taken 5.8.2010)
photograph
CAJ51.jpg  Polishing.
(taken 5.8.2010)
photograph
CAJ54.jpg  Bobbins.
(taken 5.8.2010)
photograph
CAX97.jpg  Bobbins in the drying room..
(taken 8.6.2014)
photograph
CAJ52.jpg  Sack scales.
(taken 5.8.2010)
photograph


photograph
BTH55.jpg  Pattern for water wheel rim.
(taken 5.8.2010)
photograph
BTH56.jpg  Pattern for water wheel hub.
(taken 5.8.2010)

MN photo:-
Coppice crafts:-

photograph
BLZ42.jpg  Charcoal burning kiln.
(taken 28.4.2006)
photograph
BTH31.jpg  Swill basket
(taken 5.8.2010)
photograph
BTH32.jpg  Gunpowder barrel
(taken 5.8.2010)
photograph
BTH33.jpg  Hurdle
(taken 5.8.2010)


photograph
CAJ53.jpg  Map of bobbin mills.
(taken 15.4.2014)  courtesy of Stott Park Bobbin Mill


photograph
CAJ57.jpg  Crane by the sawmill.
(taken 15.4.2014)
photograph
CAJ56.jpg  Saw bench.
(taken 15.4.2014)

hearsay:-
Built by John Harrison, 1835.
